Cannon | 3W

Product Reference

Environment Outdoor

Installation Ceiling Surface,Floor Surface,Wall Surface

Construction & Materials

Housing Milled Aluminium

Primary Lens Tempered Glass Visor

Primary Reflector PC metallised

Secondary Reflector -

Body Finish Black,Grey

Diffuser -

Antiglare Baffle -

Thermal Management

Heat Sink Material Die cast Aluminium

Cooling Technique Passive Cooling

Optical System

Beam Direction Adjustable

Tilt Yes

Swivel No

Electrical System

Driven with Constant Current Driver

Input Voltage/Hz 220V- 240V/50-60Hz

Control Gear Included

Mounting Integral

LED Power Watts 2.6W

System Power Watts 3.3W

Operating Voltage Vin 220-240 Vac

Power Factor p.f. > 0.95

LED Technology

Binning 3 Step MacAdam

LED Life Time @ L70/B10 >50000 hours

Colour Rendering (CRI) CRI80,CRI90

Led Type COB

LED Fitted High Power 3Vdc/700mA

Controls

Standard Switchable On/Off

Optional Non Dimmable
