Product Reference
Environment Indoor
Installation Ceiling Recess
Construction & Materials
Housing Aluminium
Primary Lens -
Primary Reflector -
Secondary Reflector -
Body Finish Anodised Aluminium
Diffuser Opal PC
Antiglare Baffle -
Thermal Management
Heat Sink Material Aluminium
Cooling Technique Passive Cooling
Optical System
Beam Direction Fixed
Tilt No
Swivel No
Electrical System
Driven with Constant Voltage Driver
Input Voltage/Hz 220V- 240V/50-60Hz
Control Gear Included
Mounting Remote
LED Power Watts 13.4
System Power Watts -
Operating Voltage Vin 220V- 240V/50-60Hz
Power Factor p.f. >0.95
LED Technology
Binning 3 Step MacAdam
LED Life Time @ L80/B10 >50000 hours
Colour Rendering (CRI) CRI80
Led Type SMD mid power
LED Fitted SMD mid power
Controls
Standard Switchable On/Off
Optional DDIM
Light Distribution
IES Files
Ordering Details
Code Example:
Select one from each column with highlighted values to create the ordering code
