Linescape 2315 100 | 15W

Product Reference

Environment Indoor

Installation Ceiling Recess

Construction & Materials

Housing Aluminium

Primary Lens -

Primary Reflector -

Secondary Reflector -

Body Finish Anodised Aluminium

Diffuser Opal PC

Antiglare Baffle -

Thermal Management

Heat Sink Material Aluminium

Cooling Technique Passive Cooling

Optical System

Beam Direction Fixed

Tilt No

Swivel No

Electrical System

Driven with Constant Voltage Driver

Input Voltage/Hz 220V- 240V/50-60Hz

Control Gear Included

Mounting Remote

LED Power Watts 14.4

System Power Watts -

Operating Voltage Vin 220V- 240V/50-60Hz

Power Factor p.f. >0.95

LED Technology

Binning 3 Step MacAdam

LED Life Time @ L70/B10 >50000 hours

Colour Rendering (CRI) CRI90

Led Type SMD mid power

LED Fitted SMD mid power

Controls

Standard Switchable On/Off

Optional DDIM

Ordering Details

Code Example:

Name Watt CCT CRI Angle Finish Control
Linescape 2315 100 15W WW27K CRI90 110° AL On/Off

Select one from each column with highlighted values to create the ordering code

NAME WATT LUMEN EFFICACY CCT CRI ANGLE FINISH CONTROL
Linescape 2315 100 15W 720 50 2700K WW27K CRI90 110° Anodised Aluminium AL Non Dimmable On/Off
749 52 3000K WW30K Dali Dimmable DDIM
792 55 4000K NW40K
821 57 5700K CW57K
Linescape 2315 100 15W WW27K CRI90 110° AL On/Off
